Y38-1
SDCNC
Model | Y38-1 |
Precision | JB179-83.7 |
Maximum processing modulus | Steel m6 |
Casting m8 | |
Maximum diameter of processed cylindrical spur gear | With back column 450mm |
Without back column 800mm | |
Minimum diameter of cylindrical spur gear to be machined | To 0 |
Maximum diameter of cylindrical helical gear | 500mm when the spiral angle is 30 ° |
190mm when the spiral angle is 60° | |
Maximum milling tooth thickness (when milling spur gears) | 250mm |
Speed range of hob spindle | 47.5-192r/min |
Speed steps of hob spindle | 7 steps |
Total motor capacity | 4.125kw |
Main motor capacity | 4kw |
Dimension | 2290x1100x1910mm |
Weight | 3500kg |
